EN 10028-3 P355N is a weldable fine-grain normalized steel grade widely used in pressure vessels, boilers, and pipelines. The EN 10028-3 standard specifies flat products made of steels for pressure purposes, covering grades for room temperature, high temperature, and low-temperature service. This guide explains the product specification, available dimensions, chemical and mechanical properties, applications, and the key points to consider when ordering the plate.
Standard and Grade Overview
P355N is one of the fine-grain normalized steels in the EN 10028-3 series, which also includes P275NH, P355NH, P355NL1, P355NL2, P460NH, P460NL1, P460NL2, P275NL1, and P275NL2. The designation P identifies pressure purposes, 355 is the minimum yield strength in MPa for the thinnest thickness group, and N indicates delivery in the normalized condition. Normalization is performed at about 900 to 950 C, and the plate is typically held in the furnace after temperature equalization for approximately one minute per millimeter of thickness before cooling, which refines the grain and stabilizes the mechanical properties.
Available Dimensions and Delivery
P355N plates are commonly available in thicknesses from 6 to 250 mm, widths from 1150 to 3700 mm, and lengths from 3000 to 18000 mm. The minimum order quantity is typically two pieces, and standard delivery times are 20 to 35 days. Common trade terms include FOB, CFR, and CIF, with payment by T/T or irrevocable at-sight L/C. Processing services commonly offered include cutting, welding, sand blasting, painting, ultrasonic flaw detection to Grade 1 or Grade 2, heat treatment, and galvanizing, and these should be confirmed with the supplier when the order is placed.
Chemical and Mechanical Properties
The heat analysis of P355N is limited to carbon 0.20%, silicon 0.50%, manganese 0.90 to 1.70%, phosphorus 0.03%, sulfur 0.03%, copper 0.30%, niobium 0.05%, titanium 0.03%, chromium 0.30%, molybdenum 0.08%, nickel 0.50%, aluminum 0.020%, and vanadium 0.10%, with the values being maximums unless a range is shown. For plates up to 35 mm, the minimum yield strength is 355 MPa and the tensile strength is 490 to 630 MPa with a minimum elongation of 22%. From 35 to 50 mm the minimum yield strength is 345 MPa; from 50 to 70 mm it is 325 MPa; from 70 to 100 mm it is 315 MPa with a tensile strength of 470 to 610 MPa and elongation of 21%; and above 100 mm it is 295 MPa with a tensile strength of 450 to 590 MPa and elongation of 21%.
Applications
P355N is used for pressure vessels, industrial boilers, and heat exchangers; oil and gas storage tanks and liquefied gas cylinders; high-pressure pipelines and hydropower station components; and reactors, separators, turbine casings, and other industrial equipment. The grade is a high-quality weldable fine-grain normalized steel suitable for pressure vessels, boilers, and pipelines across the petroleum, chemical, power, and hydropower industries. Its combination of weldability, toughness, and stable normalized properties makes it a versatile choice for fabricated pressure equipment.
Purchasing Considerations
When ordering EN 10028-3 P355N plates, the thickness, width, length, and quantity should be defined together with the required mechanical tests and certification documents, such as an EN 10204 type 3.1 mill certificate. Impact testing requirements and any supplementary processing such as cutting, edge preparation, or flaw detection should be stated in the inquiry. For projects in cold regions, the low-temperature sub-grades such as P355NL1 or P355NL2 should be considered, while the NH grade is preferred for elevated temperature service. The design temperature range and the governing code allowable stresses should be verified with the supplier before finalizing the order.
Frequently Asked Questions
What is the difference between P355GH and P355NH?
P355GH is designed for high-temperature applications and is characterized by high strength at temperatures up to about 500 C. P355NH is designed for low-temperature applications and is characterized by high toughness at low temperatures.
What is P355GH equivalent to in ASTM material?
P355GH pressure vessel steel is approximately equivalent to ASTM A516 Grade 70 and ASME SA516 Grade 70 in strength level, although the specifications differ in chemical limits and testing rules.
What is P355NH material?
P355NH is a pressure vessel steel grade with good weldability and high resistance to brittle cracking, used by fabricators for the manufacture of pressure vessel tanks for the storage of pressurized gases.
What is the temperature range of P355NH?
Its most widespread use is in application environments up to 400 C. P355NH steel is supplied in the normalized condition; the normalizing temperature is 900 to 950 C, and the plate is left in the furnace after temperature equalization for approximately one minute per millimeter of thickness.
What delivery documents are typical for P355N plates?
Plates are normally supplied with a mill test certificate under EN 10204 type 3.1, and third-party inspection can be arranged when required. The certificate records the chemical analysis, mechanical test results, and the heat treatment condition.
What sizes are available for P355N plates?
Thicknesses from 6 to 250 mm, widths from 1150 to 3700 mm, and lengths from 3000 to 18000 mm are commonly available, with the minimum order quantity typically two pieces.
