Structural A36 Steel Wide Flange H Beam Section W16x57
W16x57 wide flange h beam basic parameters
Dimensions
Cross-section dimensions: 417mm (waist height) × 181mm (leg width) × 10.9mm (waist thickness) × 18.2mm (leg thickness).
Single beam weight: about 85kg/meter.
Length range: conventional 12 meters, support customization.
Implementation standard: ASTM A36/A36M (American standard carbon structural steel).
Mechanical properties
Yield strength ≥ 250MPa
Tensile strength 400-550MPa
Elongation ≥ 23% (similar to national standard Q235B).
W16x57 wf steel beam advantages and characteristics
Corrosion resistance: The surface is rust-proofed and suitable for humid or corrosive environments.
High strength and light weight: The cross-section design is optimized, and the load-bearing capacity is better than that of ordinary I-beams.
Easy to process: Support cutting and welding, and adapt to mechanical manufacturing needs.
W16x57 w flange beam Applicable scenarios
Construction field: high-rise steel structure, factory frame.
Machinery manufacturing: equipment bracket, mechanical connector.
Bridge engineering: as supporting structure or auxiliary component.
| All specifications products can be customized according to customer requirements | |
| Grade | S355JR h type beam,S275JR steel beam,S355J2 h beam steel structure,S355J0 h section beam,S355NL h section steel,S355ML structural steel beam,A36 w flange beam,A572GR50 w shape beam,A992 w shape structural steel etc. |
| Standard | ASTM bs GB EN JIS DIN etc |
| Length | 6M,8m,9m,11m,12m or Customer's requirements |
| Flange Width | 100-300mm or Customer's requirements |
| Flange Thickness | 5-30mm or Customer's requirements |
| Web Width | 100mm~900mm or Customer's requirements |
| Model Number | H100*100-900*300 |
| Web Thickness | 5-30mm or Customer's requirements |
| Payment | T/T, D/A, D/P, L/C, Western Union, MoneyGram or according to customer requirements. |
| MOQ | 1 TON, can be customized according to your requirements. |
| Application | Widely used in building construction, building concrete
1.Industrial structure of the steel structure bearing bracket. 3. Petrochemical and electric power and other industrial equipment structure. 4.Large span steel bridge components. 5.Ships, machinery manufacturing frame structure. 6.The train, automobile, tractor beam bracket. 7.Port of conveyor belt, high speed damper bracket. |
