W14x398 Wide Flange Beam in ASTM A572 Grade 50: Dimensions and Properties

May 20, 2025 Leave a message

What the W14x398 Designation Means

W14x398 is an American wide flange shape, part of the W series of hot-rolled structural sections. The first number, 14, is the nominal depth in inches, and the second number, 398, is the nominal mass in pounds per linear foot. For heavy shapes in the W14 group the actual depth exceeds the nominal value, and W14x398 is no exception: its true depth is about 18.29 in, or 464.6 mm. The designation carries no information about flange width at all, so the section properties must always be taken from the rolled shape table rather than inferred from the name.

Dimensions and Section Properties of W14x398

Property Imperial Metric
Depth, d 18.29 in 464.6 mm
Flange width, bf 16.59 in 421.4 mm
Web thickness, tw 1.77 in 45.0 mm
Flange thickness, tf 2.85 in 72.4 mm
Cross-sectional area 117 in2 75 480 mm2
Mass 398 lb/ft 592 kg/m
Second moment of area, strong axis 6000 in4 2.50 x 10^9 mm4
Elastic section modulus, strong axis 656 in3 10.75 x 10^6 mm3
Plastic section modulus, strong axis 726 in3 11.90 x 10^6 mm3
Radius of gyration, strong axis 7.16 in 181.8 mm
Radius of gyration, weak axis 3.01 in 76.5 mm

The very heavy flanges, 72.4 mm thick and 421.4 mm wide, give the section a compact profile that develops its full plastic moment without local flange buckling. The 45 mm web keeps shear stresses low and needs only sparse stiffening under normal building loads.

ASTM A572 Grade 50 Material

W14x398 is frequently rolled in ASTM A572 Grade 50, a high-strength low-alloy structural steel. The grade delivers a minimum yield strength of 345 MPa, equivalent to 50 ksi, and a minimum tensile strength of 450 MPa, equivalent to 65 ksi, which is roughly 45% stronger than an ordinary 235 MPa structural grade. Typical chemistry limits for the grade are 0.23% maximum carbon, 1.35% maximum manganese, 0.40% maximum silicon, 0.04% maximum phosphorus and 0.05% maximum sulfur, with small additions of vanadium, niobium or nitrogen used to obtain the strength by grain refinement and precipitation rather than by carbon content.

Weathering option: ASTM A572 Grade 50 can be supplied in copper-bearing variants that form a stable patina when exposed to the atmosphere.

Weldability: the low-alloy, low-carbon design keeps the carbon equivalent moderate, so the grade is welded with standard electrodes and normal preheat practice.

Alternative grades: the same W14x398 profile is also produced in ASTM A992, the default material for building frames, which has the same 345 MPa yield strength with additional limits on the yield-to-tensile ratio and upper yield strength for seismic design.

Tolerances and Quality Requirements

Hot-rolled W shapes are produced to ASTM A6, which sets dimensional tolerances for depth, flange width, web and flange thickness, out-of-squareness, sweep and camber. Because W14x398 is a heavy section, the permissible variation in flange thickness is proportionally larger than for light shapes, and a nominal-property check against the mill certificate is normal practice for heavily loaded members.

Mechanical requirements are verified on each heat: tensile testing confirms yield strength, tensile strength and elongation, and a Charpy V-notch test is available when a project specification requires a minimum toughness at a stated temperature. Mill certificates are issued to EN 10204 3.1 or equivalent for traceability of the heat number, chemistry and test results.

Applications of W14x398 Beams

At 592 kg per metre, W14x398 belongs in the heaviest structural work rather than in ordinary floor framing. Typical applications include columns and transfer girders in high-rise buildings, long-span roof trusses, crane runway girders, bridge girders, and machinery support frames where a large concentrated load must be carried over a limited depth of construction.

Because the section is compact and laterally stiff, it is efficient in members that are governed by combined axial force and bending, for example seismic moment-frame columns. The wide flange also simplifies bolted end-plate connections, since no tapered washers are needed.

Frequently Asked Questions

Q: What does the 398 in W14x398 mean?
The 398 is the nominal weight in pounds per linear foot, which corresponds to about 592 kg per metre. It is not the flange width; the actual flange width of the shape is about 16.59 in, or 421.4 mm.

Q: Why is the actual depth of W14x398 larger than 14 inches?
The W series uses a nominal depth label. Heavy members in the W14 group are rolled with actual depths well above 14 in, and W14x398 measures about 18.29 in deep.

Q: What is the yield strength of ASTM A572 Grade 50?
The specified minimum yield strength is 345 MPa, or 50 ksi, with a minimum tensile strength of 450 MPa, or 65 ksi. These figures apply to the standard structural shapes produced under the specification.

Q: Can W14x398 in A572 Grade 50 be welded?
Yes. The grade has moderate carbon and manganese levels, so ordinary shielded metal arc, gas metal arc and flux cored processes are suitable. Thick flanges need modest preheat to control cooling rate and hydrogen.

Q: Is ASTM A992 a substitute for A572 Grade 50 in W14x398?
For building frames the two grades are practically interchangeable because both specify a 345 MPa minimum yield strength. A992 adds a tighter limit on the ratio of yield to tensile strength for seismic applications, so it cannot always be replaced by A572 Grade 50.

Q: How is the section modulus used in design?
The elastic section modulus of 656 in3 multiplies the allowable bending stress to give the resisting moment. Dividing the required design moment by the section modulus shows immediately whether the shape is adequate.
