Product features of American standard H-beam w shape beam W12x35

W12x35 steel h beam is a US standard H-beam (also known as wide flange H-beam). The "W" in its specifications stands for Wide Flange, "12" means that the nominal depth of this steel is 12 inches, and "35" means that the weight per foot of length is about 35 pounds.

W12x35 h section steel material properties
Material: Usually made of A36 or A992 grade steel. A36 is ordinary carbon structural steel with good mechanical properties; A992 is a high-strength low-alloy structural steel widely used in bridges and buildings.

W12x35 h type steel beam size parameters
Depth (Height, H): The actual size is about 12.19 inches (about 310 mm).
Flange Width (Flange Width, B): About 6.52 inches (about 166 mm).
Web Thickness (Web Thickness, Tw): About 0.370 inches (about 9.4 mm).
Flange Thickness (Tf): Approximately 0.510 inches (approximately 13 mm).
Cross-sectional Area: Approximately 10.3 square inches (approximately 6645 square mm).
Unit Weight: Approximately 35 pounds per foot (approximately 15.88 kg/m).

W12x35 h shaped steel Applications
Construction Engineering: Suitable for load-bearing components such as frames, beams, and columns.
Bridge Construction: Due to its high strength and good weldability, it is suitable for the key load-bearing parts of bridges.
Industrial Plant: As the supporting structure of the plant, it can withstand large loads.
Other large steel structure projects: such as large-span buildings such as stadiums and exhibition centers.
