S355JR and Q355B are both 355 MPa yield class structural steels, and they are frequently treated as equivalent in international projects. S355JR is defined in EN 10025-2, while Q355B is the Chinese designation in GB/T 1591-2018, which replaced the former Q345B of GB/T 1591-2008. This article compares the two grades in detail and explains where equivalence holds and where it must be verified.
Grade Designations and Standards
S355JR belongs to the European hot-rolled structural steel family per EN 10025-2: S indicates structural steel, 355 is the minimum yield strength in megapascals, J refers to impact toughness, and R indicates a minimum absorbed energy of 27 J at +20 deg C. Q355B is defined in GB/T 1591-2018: Q denotes a yield-strength-guaranteed steel, 355 is the yield value, and B indicates Charpy impact testing at +20 deg C. The older Q345B designation was replaced by Q355B in the 2018 revision of GB/T 1591.
Chemical Composition Comparison
| Element (max, %) | S355JR (EN 10025-2) | Q355B (GB/T 1591) |
|---|---|---|
| Carbon (C) | 0.24 | 0.24 |
| Manganese (Mn) | 1.60 | 1.60 |
| Phosphorus (P) | 0.035 | 0.035 |
| Sulfur (S) | 0.035 | 0.035 |
| Silicon (Si) | 0.55 | 0.55 |
| Nitrogen (N) | 0.012 | 0.012 |
| Copper (Cu) | 0.55 | 0.40 |
The two grades have nearly identical chemistry, with only a small difference in the copper maximum, which does not affect material equivalence for structural purposes. Both standards also specify carbon equivalent limits that support weldability.
Mechanical Properties Comparison
| Property (t up to 16 mm) | S355JR | Q355B |
|---|---|---|
| Yield strength, min (MPa) | 355 | 355 |
| Tensile strength (MPa) | 470-630 | 470-630 |
| Impact test temperature | +20 deg C | +20 deg C |
| Impact energy, min | 27 J | 34 J |
The strength values match for thicknesses up to 16 mm, with both standards reducing the guaranteed yield in steps for thicker material. The main difference is the impact requirement: the Chinese standard demands a slightly higher absorbed energy (34 J versus 27 J) at the same test temperature, which is a minor but real difference in toughness assurance.
Claimed Equivalents of S355JR
S355JR is commonly compared with other international grades, but each comparison must be treated with care:
ASTM A572 Grade 50: close in yield level (345 MPa minimum versus 355 MPa) and widely used as an approximate US counterpart, but the base A572 specification does not guarantee impact toughness.
DIN 17100 St50-2: a legacy German grade with similar yield and tensile levels, no longer current in new designs.
JIS SS540: not an equivalent. SS540 has a minimum tensile strength of 540 MPa and a higher yield level, so it is a stronger grade and should not be substituted for S355JR without redesign.
Practical Guidance for Substitution
For general structural use where yield and tensile strength govern, S355JR and Q355B are functionally interchangeable and are routinely substituted in international projects. Before substitution, confirm three points: the thickness-dependent yield values in the applicable standard, the impact test requirements of the design (temperature and absorbed energy), and any supplementary requirements such as Z-direction testing or normalized delivery where the design demands them.
Both grades are widely used in building frames, bridge girders, heavy equipment supports, machinery frames, transmission towers, piling, and general fabricated sections where the 355 MPa yield level is adequate.
Frequently Asked Questions
Q: Is Q355B the same as Q345B?
A: Q355B is the new designation introduced in GB/T 1591-2018 that replaced Q345B of the earlier edition. The yield level was aligned with the 355 MPa class, and the chemistry and inspection requirements follow the 2018 edition.
Q: Are S355JR and Q355B fully equivalent?
A: For strength purposes, yes: both guarantee 355 MPa minimum yield (up to 16 mm) and 470-630 MPa tensile strength. The impact requirements differ slightly (27 J versus 34 J at +20 deg C), so toughness-sensitive designs should verify the requirement.
Q: What is the yield strength of S355JR and Q355B?
A: Both guarantee a minimum yield strength of 355 MPa for thicknesses up to 16 mm, decreasing in steps for thicker material per their respective standards.
Q: What are the international equivalents of S355JR?
A: The most commonly cited approximate equivalents are ASTM A572 Grade 50 and the legacy DIN 17100 St50-2. Claims that JIS SS540 is an equivalent are incorrect, because SS540 has a higher strength level.
Q: Can Q355B be used in a project designed to EN 10025-2?
A: Yes, in most cases, provided the engineer verifies the thickness-dependent yield values and the impact requirements, since the two standards guarantee slightly different impact energies.
Q: What is the impact test difference between S355JR and Q355B?
A: Both are tested at +20 deg C, but S355JR requires at least 27 J while Q355B requires at least 34 J. The Chinese grade therefore provides a slightly higher toughness assurance.
