SA516Gr55 Vessel Steel Plate
SA516Gr55 Pressure Vessel Steel Shell Plate Product Introduction
SA516Gr55 pressure vessel plate material offered by GNEE is carbon steel plate for medium and low temperature pressure vessel, the SA516Gr55 vessel steel plate we offer is in accordance with ASME standard. The SA516Gr55 boiler steel we offer is manufactured strictly according to the standard and has passed the quality certification, we can provide the quality certificate and accept the third party testing. In addition, we can provide you with SA516Gr55 boiler plate in any size, and if you have special requirements, we can also provide customised size service.
|
Product Name |
Hot rolled Steel Plate |
|
Standard |
Boiler and pressure vessel plates |
|
GB/T713 |
Q245R, Q345R, Q370R, Q420R, 18MnMoNbR, 13MnNiMoR, 15CrMoR, 14Cr1MoR, 12Cr2Mo1R,12Cr1MoV, 12Cr2Mo1VR,07Cr2AIMoR |
|
GB/T 19189 |
07MnMoVR, 07MnNiVDR,07MnNiMoD,12MnNiVR |
|
GB/T 3531 |
16MnDR,09MnNiDR,15MnNiDR,15MnNiNbDR |
|
(ASME)ASTM |
(S)A203MGr.(A,B,D,E,F),(S)A204MGr.(A,B,C),(S)A285MGr.(A.B.C), (S)A299MGr.(A,B),(S)A302MGr.(A,B,C,D),(S)A387M Gr. (5.9,11.12,22), |
|
EN10028-2 |
P235GH, P265GH,P295GH, P355GH,16Mo3,13CrMo4-5,10CrMo9-10, 11CrMo9-10,15NiCuMoNb5-6-4,18MnM04-5 |
|
EN10028-3 |
P275(NH,NL1,NL2), P355(N,NH,NL1,NL2), P460(NH,NL1,NL2) |
|
Technique |
hot rolled |
|
Thickness |
8-200mm or as required |
|
Width |
1000-2500mm or as required |
|
Length |
6000-12000mm or as required |
|
Export packing |
Steel strips package or seaworthy packing |
SA516Gr55 Pressure Vessel Quality (PVQ) Steel Product Details
SA516Gr55 Hot Rolled Boiler Steel Plate Chemical Composition:
| Grade | C | Mn | Si | P max | S max |
| SA516 Grade 55 | 0.18-0.26 | 0.55-1.3 | 0.13-0.45 | 0.035 | 0.035 |
SA516Gr55 Boiler Grade Plate Mechanical Properties:
| Grade | Tensile Strength(MPa) | Yield Strength(MPa) min | % Elongation in 2 in.(50mm) min | Impacting Test Temperature(°C) |
| SA516 Grade 55 | 380-515 | 205 | 23 | -20,40,-60 |
SA516Gr55 Pressure Vessel (PVQ) Steel Plate Product Image
SA516Gr55 boiler steel Product packaging
GNEE Group Exhibition Pictures
GNEE Group customers visit
If you have more needs and questions about SA516Gr55 vessel steel plate, we are happy to advise you!
