British standard H-shaped steel is a kind of steel with good bearing capacity and stable performance. It is mainly used in structural projects such as high-rise buildings and bridges. It is produced to British Standards (BS) and is widely recognized as a high quality construction steel. Next, we need to master the material dimensions of British standard H-shaped steel.
British standard H-beams are available in various sizes and specifications to meet the needs of different structural projects. Generally speaking, the widths of British standard H-shaped steel mainly include 685mm, 870mm, 940mm and 1015mm. The height is generally between 588mm and 980mm.
British standard H-shaped steel UC203*203*86 (222.2*209.1*12.7*20.5) weighs 86.1 kg per meter
British standard H-shaped steel UC254*254*73 (254.1*254.6*8.6*14.2) weighs 73.1 kg per meter
British standard H-shaped steel UC254*254*89 (260.3*256.3*10.3*17.3) weighs 88.9 kg per meter
British standard H-shaped steel UC254*254*107 (266.7*258.8*12.8*20.5) weight per meter 107.1 kg
British standard H-shaped steel UC254*254*132 (276.3*261.3*15.3*25.3) weighs 132 kg per meter
British standard H-shaped steel UC254*254*167 (289.1*265.2*19.2*31.7) weight per meter 167.1 kg
The web thickness of British standard H-shaped steel is usually between 12mm and 30mm, and the flange thickness is between 8mm and 20mm. In practical applications, the size of British standard H-shaped steel can be adjusted according to actual needs. At the same time, British standard H-shaped steel also has good interchangeability and can be flexibly applied according to different design plans and needs. In addition, British standard H-shaped steel also has high fatigue resistance and torsion resistance, which can effectively improve the stability and safety of structural engineering.
British standard H-shaped steel is a high-quality construction steel with a wide range of applications and diverse size specifications. Mastering its material dimensions is of great significance to both architectural design and construction.
