Product Description
Q500NH Corten Steel Plate is a premium-grade high-strength weathering steel under the GB/T 4171 standard.
Engineered for outstanding atmospheric corrosion resistance, it develops a stable rust-like protective surface layer when exposed to the environment, which reduces the need for painting or additional coating.
With a minimum yield strength of 500 MPa and tensile strength ranging from 600–760 MPa, Q500NH Corten Steel Plate is ideal for structural and architectural projects that require both durability and aesthetics.
This steel grade offers cost efficiency compared to stainless steel, as it uses only trace amounts of alloying elements such as copper, nickel, chromium, molybdenum, vanadium, and titanium.
Specifications
Grade: Q500NH
Standard: GB/T 4171-2008
Type: Steel Plate / Steel Sheet
Technique: Hot Rolled
Heat Treatment: As Rolled / Normalized / TMCP / Quenched + Tempered
Thickness: 3 – 300 mm
Width: 1000 – 4200 mm
Length: 3000 – 18000 mm
Surface Finish: Rust-treatment clean, shot blasting, painted, or coated film
Chemical Composition (% Max)
| Element | C | Si | Mn | P | S |
|---|---|---|---|---|---|
| Q500NH | 0.12 | 0.65 | 2.00 | 0.025 | 0.030 |
Mechanical Properties
| Yield Strength (MPa) | Tensile Strength (MPa) | Elongation (%) |
|---|---|---|
| 480 – 500 | 600 – 760 | ≥15 |
Advantages of Q500NH Corten Steel Plate
Excellent Weather Resistance – Ideal for outdoor use in industrial, coastal, and high-humidity areas.
Low Maintenance – Naturally formed protective oxide layer eliminates the need for frequent repainting.
High Strength & Toughness – Suitable for heavy-duty load-bearing applications.
Cost-Effective Alternative to Stainless Steel – Lower alloy content but similar performance for outdoor corrosion protection.
Versatile Processing – Easy to cut, bend, weld, and fabricate into customized shapes.
Applications
Q500NH Corten Steel Plate is widely used in:
- Bridge construction and structural supports
- Architectural facades and decorative panels
- Containers, railway wagons, and freight storage
- Industrial equipment such as silos, chimneys, and power plant structures
- Outdoor landscaping elements like garden planters, retaining walls, and fencing
- Marine and coastal structures where corrosion resistance is essential
