DIN 1.0490 DIN EN 10025-3

DIN 1.0490 DIN EN 10025-3

EN 1.0490 steel is a carbon (non-alloy) steel formulated for primary forming into wrought products. Cited properties are appropriate for the normalized condition. 1.0490 is the EN numeric designation for this material. S275N is the EN chemical designation.

It has a fairly high base cost among wrought carbon or non-alloy steels. In addition, it has a fairly low thermal conductivity and a fairly high embodied energy.

The material 1.0490 belongs to the material group "Fine Grain Structural Steels". The steel material "1.0490" has three alternative names. We also have the chemical analysis of 1.0490 available for you below. The material "1.0490" contains Carbon, Chrome, Copper, Manganese, Molybdenum, Niobium, Nitrogen, Phosphorus, Silicon, Sulfur, Titanium and Vanadium. For the future we plan to add mechanical properties of "1.0490", complete data-sheets as well as a PDF-Download for you to download. For now you can easyily inquire this steel-material without obligation by using our contact-form. For correct determination of the shipping costs we need your shipping address. Please keep in mind that a detailed calculation can take a few days, depending on quantity, shipping-adress as well as forms and materials. We will contact you in any case.

Steel Grade 1.0490 composition information, DIN 1.0490 DIN EN 10025-3 element content, DIN 1.0490 DIN EN 10025-3 Heat treatment, DIN 1.0490 DIN EN 10025-3 chemistry

Carbon (C%)≤0,18

Silicon (Si%)≤0,40

Manganese (Mn%)0,50-1,50

Phosphorus (P%)0,03

Sulfur (S%)0,025

Cobalt (Co%)

Chrome (Cr%)≤0,30

Aluminum (Al%)≥0,02

Copper (Cu%)≤0,55

Nitrogen (N%)0,015

Plumb (Pb%)

Molybdenum (Mo%)≤0,10

Niobium (Nb%)≤0,05

Nickel (Ni%)

Titanium (Ti%)≤0,05

Vanadium (V%)≤0,05

Tungsten (W%)

Tellurium (Te%)

Bismuth (Bi%)

Beryllium (Be%)

Boron (B%)

Oxygen (O%)

Iron(Ferrum) (Fe%)

Hydrogen (H%)

Zirconium (Zr%)

Lanthanum (La%)

Magnesium (Mg%)

Cerium (Ce%)

Tantalum (Ta%)

Arsenic (As%)

Tin (Sn%)

Calcium (Ca%)

Yttrium (Y%)

Hydrogen content (H ppm%)

Selenium (Se%)

Hafnium (Hf%)

Antimony (Sb%)

Density7,85

GNEE Steel was established in 2008. The company has sufficient inventory, the most complete varieties, the most stable supply, and the most timely supply. With our high-quality products and good services, we have customers all over the world. We have a series of automation Equipment, ready to meet your needs, ensuring customer satisfaction.

If you have more needs and questions about DIN 1.0490 DIN EN 10025-3 steel, please contact us!
