Products Description
HPS 100W is specified in ASTM A 709 (Standard Specification for Carbon and High-Strength Low-Alloy Structural Steel Shapes, Plates, and Bars and Quenched-and-Tempered Alloy Structural Steel Plates for Bridges) and is being added to AASHTO M270.
Initial applications were planned to be those in which an owner bridge engineer would approve the use of HPS 100W. This steel would be most useful for depth control over piers in long-span girder bridges or controlling the size of high-stressed elements in long-span steel truss bridges. This datasheet provides information on composition and tensile properties.
Products Specification
|
Gangsteel Grade : |
A709 Grade 100 |
|
Specification: |
Thickness 8mm-300mm, Width: 1500-4020mm, Length: 3000-27000mm |
|
Standard: |
ASTM A709: Standard Specification for Structural Steel for Bridges |
|
Approval By Third Party |
ABS, DNV, GL, CCS, LR , RINA, KR, TUV, CE |
|
Classification: |
Structural Steel for Bridges |
Chemical Composition( %)
|
Grade/ Material |
Element |
Composition( Max-A, Min-I) |
|
A709 Grade 100W/ A709 Gr100W |
C |
A:0.15-0.21 |
|
Mn |
0.80-1.10 |
|
|
Si |
0.40-0.80 |
|
|
P |
A:0.035 |
|
|
S |
A:0.035 |
Mechanical Properties( Mpa)
|
Grade/ Material |
Tensile Test |
MPa |
|
A709 Grade 100W/ A709 Gr100W |
Tensile Strength |
690-895 |
|
Yield Strength |
I:620 |
|
|
Elongation |
I:18% |
|
|
Impact Test( if any) |
ASTM A709 Grade 100W (A709 Gr.100W) Steel Plate Applications
ASTM A709 Grade 100W steel plate is primarily used in bridge construction, highway infrastructure, and other large-scale engineering projects where high strength and superior atmospheric corrosion resistance are essential.
With a minimum yield strength of 690 MPa (100 ksi) and excellent weathering performance, it provides long-term durability even in harsh outdoor environments-reducing the need for painting or regular maintenance.
In bridge construction, A709 Gr.100W is often used for main girders, floor beams, cross frames, and box girders, allowing engineers to design lighter yet stronger structures with extended service life.
In highway construction, it is applied in overpasses, guardrail supports, and load-bearing members, enhancing both safety and cost-efficiency.
Additionally, this steel grade is ideal for structural components in railways, cranes, and offshore facilities, where high tensile strength and resistance to weather-induced degradation are critical.
Its combination of strength, weldability, and corrosion resistance makes A709 Grade 100W a preferred choice for sustainable, long-lasting infrastructure projects.
