What is S355J2 H Shape Beam?
Our S355J2 H-beams feature high dimensional precision, with cross-sectional tolerances strictly controlled within the tighter limits specified by EN 10034, ensuring excellent squareness and straightness between the web and flanges.
The product range covers heights from 100 mm to over 1000 mm, including the full HEA, HEB, and IPE series. Flange thickness can meet the requirements of various heavy-duty structural applications. Standard lengths range from 6000 mm to 12000 mm, and we also provide precise CNC cutting, drilling, and sectioning services according to project drawings.
All products are supplied in hot-rolled or normalized conditions, and undergo ultrasonic non-destructive testing (UT inspection). Surface finishes include standard hot-rolled black finish, shot blasting with protective coating, or hot-dip galvanizing. Each delivery is accompanied by an original EN 10204 3.1 Mill Test Certificate (MTC) for full traceability.
S355J2 H-Beam Chemical Composition (EN 10025-2)
| Element | Content (%) |
|---|---|
| C (Carbon) | ≤ 0.20 |
| Si (Silicon) | ≤ 0.55 |
| Mn (Manganese) | ≤ 1.60 |
| P (Phosphorus) | ≤ 0.025 |
| S (Sulfur) | ≤ 0.025 |
| N (Nitrogen) | ≤ 0.012 |
S355J2 H-Beam Chemical Composition (EN 10025-2)
| Element | Content (%) |
|---|---|
| C (Carbon) | ≤ 0.20 |
| Si (Silicon) | ≤ 0.55 |
| Mn (Manganese) | ≤ 1.60 |
| P (Phosphorus) | ≤ 0.025 |
| S (Sulfur) | ≤ 0.025 |
| N (Nitrogen) | ≤ 0.012 |
S355J2 H-Beam Physical Properties
| Property | Value |
|---|---|
| Density | 7.85 g/cm³ |
| Elastic Modulus (E) | ~210 GPa |
| Poisson's Ratio | ~0.30 |
| Thermal Conductivity | ~45 W/m·K |
| Coefficient of Thermal Expansion | ~12 × 10⁻⁶ /°C |
| Electrical Resistivity | ~0.15 μΩ·m |
S355J2 H-Beam Equivalent Grades
| Standard | Grade |
|---|---|
| EN (Europe) | S355J2 |
| EN (Alternative) | S355J2+N |
| DIN (Germany) | St52-3 |
| ISO | E355 |
| ASTM (USA) | A572 Grade 50 (approx. equivalent) |
| GB (China) | Q345D / Q345E (partial equivalence) |
| JIS (Japan) | SM490YB |
S355J2 H-Beam Full Size Table
HEA Series
| Section | Height (mm) | Width (mm) | Web (mm) | Flange (mm) | Weight (kg/m) |
|---|---|---|---|---|---|
| HEA 100 | 96 | 100 | 5.0 | 8.0 | 16.7 |
| HEA 120 | 114 | 120 | 5.0 | 8.0 | 19.9 |
| HEA 140 | 133 | 140 | 5.5 | 8.5 | 24.7 |
| HEA 160 | 152 | 160 | 6.0 | 9.0 | 30.4 |
| HEA 180 | 171 | 180 | 6.0 | 9.5 | 35.5 |
| HEA 200 | 190 | 200 | 6.5 | 10.0 | 42.3 |
| HEA 220 | 210 | 220 | 7.0 | 11.0 | 50.5 |
| HEA 240 | 230 | 240 | 7.5 | 12.0 | 60.3 |
HEB Series
| Section | Height (mm) | Width (mm) | Web (mm) | Flange (mm) | Weight (kg/m) |
|---|---|---|---|---|---|
| HEB 100 | 100 | 100 | 6.0 | 10.0 | 20.4 |
| HEB 120 | 120 | 120 | 6.5 | 11.0 | 26.7 |
| HEB 140 | 140 | 140 | 7.0 | 12.0 | 33.7 |
| HEB 160 | 160 | 160 | 8.0 | 13.0 | 42.6 |
| HEB 180 | 180 | 180 | 8.5 | 14.0 | 51.2 |
| HEB 200 | 200 | 200 | 9.0 | 15.0 | 61.3 |
| HEB 220 | 220 | 220 | 9.5 | 16.0 | 73.0 |
| HEB 240 | 240 | 240 | 10.0 | 17.0 | 85.0 |
| HEB 260 | 260 | 260 | 10.0 | 17.5 | 93.0 |
| HEB 300 | 300 | 300 | 11.0 | 19.0 | 117.0 |
IPE Series
| Section | Height (mm) | Width (mm) | Web (mm) | Flange (mm) | Weight (kg/m) |
|---|---|---|---|---|---|
| IPE 80 | 80 | 46 | 3.8 | 5.2 | 6.0 |
| IPE 100 | 100 | 55 | 4.1 | 5.7 | 8.1 |
| IPE 120 | 120 | 64 | 4.4 | 6.3 | 10.4 |
| IPE 140 | 140 | 73 | 4.7 | 6.9 | 12.9 |
| IPE 160 | 160 | 82 | 5.0 | 7.4 | 15.8 |
| IPE 180 | 180 | 91 | 5.3 | 8.0 | 18.8 |
| IPE 200 | 200 | 100 | 5.6 | 8.5 | 22.4 |
| IPE 220 | 220 | 110 | 5.9 | 9.2 | 26.2 |
| IPE 240 | 240 | 120 | 6.2 | 9.8 | 30.7 |
Extensive in-stock availability of S355J2 H-beams in various sizes and sections (HEA, HEB, IPE) enables us to deliver fast, flexible, and cost-efficient solutions for demanding construction and engineering projects.
Contact now to get the S355J2 H-beams Stock List
S355J2 H-Beam Tolerance Table (EN 10034)
| Category | Item | Tolerance |
|---|---|---|
| Dimensional Tolerance | Height (h) | ±2.0 mm (small sections) / up to ±3.0 mm (large sections) |
| Dimensional Tolerance | Flange width (b) | ±2.0 mm |
| Dimensional Tolerance | Web thickness | ±0.5 – 1.0 mm |
| Dimensional Tolerance | Flange thickness | ±0.8 – 1.5 mm |
| Length Tolerance | Standard length | ±50 mm |
| Shape Tolerance | Straightness | ≤ L/1000 |
| Shape Tolerance | Squareness | 90° ± 2° |
| Shape Tolerance | Flange out-of-flatness | ≤ 5 mm/m |
| Weight Tolerance | Theoretical weight deviation | ±2% – ±4% |
S355J2 H-Beam Applications
S355J2 H-beams are widely used in high-strength structural and engineering applications.
In building construction, they are commonly used for load-bearing beams, columns, floor support systems, and high-rise steel frame structures, where high structural stability and safety are required.
In bridge engineering, S355J2 H-beams are used for main girders, support structures, and secondary load-bearing components, offering reliable performance under heavy dynamic and static loads.
In industrial construction, they are applied in factory buildings, steel platforms, warehouses, and heavy equipment support frames that require durable and high-strength steel sections.
S355J2 H-Beam Lead Time
The lead time for S355J2 H-beams depends on stock availability and production requirements.
Stock items: 7–15 business days. This includes order confirmation, material inspection, cutting (if required), packing, and outbound shipment processing.
New production: 3–5 weeks. This covers steel rolling, heat treatment (if required), dimensional adjustment, surface preparation, and quality inspection before delivery.
For urgent or project-based requirements, faster delivery schedules can be arranged depending on section size and order quantity.
S355J2 H-Beam Processing Services
We provide a full range of processing services for S355J2 H-beams to meet different structural and engineering project requirements.
Cutting Services: Precision cutting to fixed lengths or project-specific dimensions using saw cutting or CNC equipment, ensuring accurate sizing and smooth end finishes.
Drilling & Punching: CNC drilling and punching services according to structural drawings, suitable for bolted connections in steel structures, bridges, and industrial frameworks.
Welding & Assembly: Custom welding services for fabricated steel components, including beam-to-column connections and pre-assembled structural units.
Surface Treatment: Shot blasting (Sa 2.5) for rust and scale removal, followed by protective painting or coating systems to improve corrosion resistance. Hot-dip galvanizing is also available for long-term outdoor applications.
Straightening & Alignment: Mechanical straightening to correct deformation and ensure compliance with structural tolerances before delivery.
Customized Fabrication: Project-based fabrication services including end preparation, beveling, marking, and pre-assembly according to customer drawings and specifications.
S355J2 H-Beam Inspection & Testing
We can provide a full range of inspection and testing services for S355J2 H-beams to ensure compliance with EN 10025-2 and project requirements.
Mechanical Testing: Includes tensile testing to determine yield strength (ReH), tensile strength (Rm), and elongation, ensuring compliance with S355J2 mechanical property requirements.
Ultrasonic Testing (UT): Used to inspect internal quality of the H-beam, detecting defects such as cracks, inclusions, or internal discontinuities.
Dimensional Inspection: Measures height, flange width, web thickness, and length to ensure compliance with EN 10034 tolerances.
Surface Inspection: Visual and instrumental checks for surface defects such as cracks, rust, lamination, or rolling marks.
Impact Testing (if required): Charpy V-notch test at -20°C to verify impact energy ≥ 27 J, ensuring low-temperature toughness performance.
Certification: EN 10204 3.1 or 3.2 Mill Test Certificates (MTC) are available for full traceability and quality assurance.
S355J2 H-Beam Packaging & Protection
We provide professional export-grade packaging solutions to ensure safe transportation and prevent mechanical damage during handling, loading, and shipping.
All S355J2 H-beams are bundled using high-strength galvanized steel straps at regular intervals to maintain structural stability and prevent deformation during transit.
Surface protection is applied according to customer requirements, including anti-rust oil coating, waterproof plastic wrapping, or protective film to prevent moisture, corrosion, and surface scratches.
Each bundle is fixed on reinforced wooden skids or steel pallets compliant with ISPM 15 (IPPC) international export standards, ensuring suitability for sea freight and global shipment.
Additional protection materials such as rubber pads or wooden spacers can be used at contact points to avoid surface indentation and minimize friction between steel sections.
All packages are clearly marked with grade, size, heat number, and bundle identification to ensure full traceability and easy on-site verification.
