A36 A588 H Profile Steel
ASTM A588 is a standard specification for high-strength, low-alloy steel with a minimum yield point of 50 ksi. American Society for Testing and Materials G101 requires the corrosion resistance index to be no less than 6.0.
A36 carbon steel is a material used in a wide range of applications due to its low cost and wide range of desirable properties, including weldability, formability, strength and toughness. Most applications for A36 steel are structural, such as bridges and buildings. A36 steel is also used in the automotive, construction, heavy machinery, and oil and gas industries.
structural steel h beam Products Details
| Name | A36 A588 H Profile Steel |
| Type | A36 A588 |
| Size | 100mm*100m - 900mm*300mm |
| Technique | hot rolled, welded |
| Grade |
Q235,Q355,SS400,S235,S355,ST37,ST52,E250,E350, A36,A572GR50,A992,G350,SM460,SM490,A992,etc |
| Surface | Surface painted, galvanized |
| Packing | in bundle, packed with steel belts tightly |
| Origin | China |
| Sample | yes |
a588 steel h beam chemical composition
| Grade | C % | Si % | Mn % | P % | S % | Cr % | V % | Ni % | Cu % |
| A588 Gr A | 0.19 | 0.30-0.65 | 0.80-1.25 | 0.04 | 0.05 | 0.40-0.65 | 0.02-0.10 | 0.40 | 0.25-0.5 |
| A588 Gr B | ≤0.20 | 0.15-0.50 | 0.75-1.35 | 0.040 | 0.050 | 0.40-0.70 | 0.01-0.10 | ≤0.50 | ≤0.50 |
a36 h shaped steel chemical composition
| Element | Percentage |
|---|---|
|
Iron |
98% |
|
Manganese |
1.03% |
|
Carbon |
0.25%–0.29% |
|
Silicon |
0.28% |
|
Copper |
0.20% |
|
Sulfur |
0.05% |
|
Phosphorous |
0.04% |
a588 h section steel mechanical property
| Grade | Thickness | Yield Strength ReH[N/mm2]transv.min |
TensileStrength Rm[N/mm2]transv |
| ASTM A588 | 0mm-100mm | 340 MPa | 480 MPa |
| 102mm-127mm | 320 MPa | 460 MPa | |
| 127mm-203mm | 290 MPa | 430 MPa |
a36 structural h beam mechanical property
| Property | Value |
|---|---|
|
Density |
2.84 lb/in^3 |
|
Yield strength |
36,259 psi |
|
Hardness |
67–83 Rockwell |
|
Magnetism |
Ferrous magnetic |
A36 H shaped steel application
A36 H-beam is mainly used for beams and columns in industrial and civil structures.
◆Steel structure load-bearing bracket of industrial structures
◆ Steel piles and supporting structure of underground engineering
◆ Petrochemical and electric power and other industrial equipment structure
◆ Large-span steel bridge components
◆ Ship, machinery manufacturing frame structure
◆Trains, automobiles, tractor beam supports
◆ Harbour conveyor belt, high-speed baffle bracket
