S355G9+M steel channe
Products Description
S355G9+M channel steel is a structural hot-rolled steel with high strength and good weldability. The material complies with en10225 and is suitable for Marine structures and offshore engineering. Among them, S355 indicates that the minimum yield strength of the steel is 355MPa, G9 indicates that the maximum thickness that needs to control the difference is 9mm, and M indicates weldability.
Products Details
S355G9+M steel channe product Introduction：
|
Product name |
S355G9+M steel channe | ||
|
Size |
100mm-900mm |
||
|
Wall thickness |
1.5mm-28mm |
||
|
Length |
6m-12m ,by customer's requiremnts |
||
|
Internatioanal Standard |
ISO 9001-2008 / ISO 630 / JIS / ASTM/etc |
||
|
Standards |
ASTMA53/ASTM A573/ASTM A283/Gr.D/BS1387-1985/ GB/T3091- 2001,GB/T13793-92, ISO630/E235B/JIS G3101/JIS G3131/JIS G3106/ |
||
|
Materials |
Q195,Q215,Q235B,Q345B, S235JR/S235/S355JR/S355SS440/SM400A/SM400B/etc |
||
|
Product Category |
Metallurgy,Mineral & Energy |
||
|
Technique |
HOT ROLLED |
||
|
|
1.Big OD:in bulk |
||
|
Usage |
Mechanical & manufacture,Steel strcuture, |
||
|
Country of origin |
China |
||
|
Productivity |
15000 Metric Tons pet Month |
||
|
Another Name |
Hot rolled mild steel I beam , I beam , H beam ,steel beam ,beam |
||
|
Surface processing |
you can Galvanized,coated,or as your request |
||
|
Technical |
Hot rolled mild steel |
||
S355G9+M structural steel channel chemical composition
| C | Si | Mn | P | S | Cr | Mo | Nb+V | Nb+V+Ti |
| 0.12 | 0.15-0.55 | 1.65 | 0.020 | 0.010 | 0.20 | 0.08 | 0.06 | 0.08 |
| Ni | Alt | Cu | N | Nb | Ti | V | Cr+Mo+Ni+Cu | |
| 0.70 | 0.015-0.055 | 0.30 | 0.010 | 0.030 | 0.025 | 0.060 | - | |
S355G9+M parallel flange channel mechanical property
| Thickness (mm) | |||||||
| S355G9+M | ≤ 16 | > 16 ≤ 25 | > 25 ≤ 40 | > 40 ≤ 63 | > 63 ≤ 100 | > 100 | |
| Yield strength (≥Mpa) | 355 | 355 | 345 | 335 | 325 | 325 | |
| ≤ 100 | > 100 | ||||||
| Tensile strength (Mpa) | 470-630 | 470-630 | |||||
S355G9+M c channel beam is a high-strength structural steel plate with good weldability, corrosion resistance and low temperature toughness. It is widely used in marine engineering, shipbuilding, offshore bridges, offshore oil platforms, and marine pipelines.
about us
A group photo of the GNEE company team. We were founded in 2008. We have rich experience in steel export and have established cooperative relationships with more than 120 countries and regions around the world. If you have any steel needs, please contact us and we will provide you with high-quality services. , to meet your purchasing needs, and also welcome new and old customers to visit:
GNEE company salesmen visit customers and communicate with them to ensure better service to customers. GNEE looks forward to cooperating with more new and old customers:
Members of the Profile steel team of GNEE and other team members explained the goals of this event. In the following work, they will work hard to achieve their own customized goals:
GNEE Group office environment display, welcome new and old customers to visit. At the same time, if you have any questions about angle iron, you can contact us and we will reply to you in the shortest time:
When GNEE customers visited the company, the salesperson warmly received them and took photos. We look forward to more cooperation from new and old customers, and also warmly welcome your visit:
qualifications and honors
GNEE company has passed SGS CE ISO and other certifications, has complete testing equipment, strong technical force, and accepts factory testing. We firmly believe that "quality is the core of a company's sustainable strength". We will establish stable, long-term, win-win cooperative relationships with our customers and stick to them:
cooperation factories
GNEE Company has signed first-level agency agreements with some large steel plants such as Baosteel, Maanshan Iron and Steel, and Anshan Iron and Steel, which has a strong price war advantage. We are committed to strict quality control and thoughtful customer service, and our experienced staff are always ready to listen to your requirements to ensure full customer satisfaction:
packaging & shipping
We can provide professional services, we have S355G9+M Steel Channe and H profile steel and other products in stock, if you have any needs, please contact us.
FAQ
A: We are manufacturer and trade.
Q: Do you provide samples? Is it free or extra ?
A: Yes, we could offer the sample for free, but the buyers should bear the courier fee.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q: How long is your delivery time?
A: Generally it is 7-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
