A572 A514 Channel Steel
ASTMA572 is a high-strength low-alloy steel containing niobium and vanadium, which can increase the strength of the steel and make its yield point strength higher than ASTMA36. Since the A572 HSLA channel has higher strength requirements, its thickness and weight can be reduced.
ASTM A514 steel plate, also known as T-1 steel plate, is known for its low-temperature toughness and plays an important role in the nation's infrastructure. A514 steel is widely used in house and bridge structures due to its high yield strength and good welding properties.
A572 A514 Channel Steel Basic Info
| Name | A572 A514 Channel Steel |
| Type | A572 A514 etc |
| Size | 5# - 10# |
| Thickness | 3mm - 14.5mm |
| Length | 6m,9m,12m or other length based on your demand |
| Shape | C or U |
| Grade |
Q235,Q355,SS400,S235,S355,ST37,ST52,E250,E350, A36,A572GR50,A992,G350,SM460,SM490,A992,etc |
| Surface | Surface painted, galvanized |
| Packing | in bundle, packed with steel belts tightly |
| Origin | China |
| Sample | yes |
a572 c channel chemical composition
| Item | Grade | Carbon, max, % | Manganese, max, % | Silicon, max, % | Phosphorus, max, % | Sulfur, max, % |
|---|---|---|---|---|---|---|
| A572 | 42 | 0.21 | 1.35 | 0.40 | 0.04 | 0.05 |
| 50 | 0.23 | 1.35 | 0.40 | 0.04 | 0.05 | |
| 55 | 0.25 | 1.35 | 0.40 | 0.04 | 0.05 |
| Item | Grade | Yield point, min, ksi [MPa] | Tensile strength, min, ksi [MPa] |
|---|---|---|---|
| A572 steel angle | 42 | 42 290] | 60 [415] |
| 50 | 50 [345] | 65 [450] | |
| 55 | 55 [380] | 70 [485] |
a514 c section steel chemical composition
|
SI |
FE |
MN |
CR |
MO |
TI |
B |
V |
C |
|
0.28% |
98.0% |
0.85% |
0.48% |
0.2% |
0.02% |
0.003% |
0.05% |
0.27 - 0.30% |
a514 channel beam mechanical property
|
|
Metric |
Imperial |
|
Tensile Strength, Ultimate |
760 - 895 MPa |
110,000 - 130,000 psi |
|
Tensile Strength, Yield |
690 MPa |
100,000 psi |
|
Elongation at Break (in 50 mm) |
18% |
18% |
|
Modulus Elasticity |
190 - 210 GPa |
27,557 - 30,458 ksi |
|
Bulk Modulus (Typical for Steel) |
140 GPa |
203,000 ksi |
|
Poissons Ratio |
0.27 - 0.30 |
0.27 - 0.30 |
|
Shear Modulus (Typical for Steel) |
80 GPa |
116,000 ksi |
about GNEE group
GNEE (Tianjin) Multinational Trade Co., Ltd. is mainly engaged in the import and export of steel products and the deep processing of steel products. Founded in 2008, it currently has more than 200 employees. Mainly engaged in square tubes, channel steel, angle steel, I-beam, H-shaped steel, seamless steel pipes, open plates, flower formwork, welded pipes, galvanized steel, round steel, flat steel, PPGI, hot-rolled, etc. Our products have been exported to more than 120 countries in Europe, the Middle East, Southeast Asia, Australia, etc. We have won the recognition of our customers with our good reputation and good service. We sincerely welcome friends from all over the world to visit our company and cooperate with us on the basis of long-term mutual benefit. We look forward to receiving your inquiry as soon as possible:
GNEE company’s August-September activities use games to increase team cohesion and demonstrate the unity of the team. At the same time, through this activity, we can cultivate the cooperation ability among employees:
GNEE company’s office environment and employee work style are displayed. New and old customers are welcome to visit. We will welcome your visit with great enthusiasm and provide you with professional steel services:
When GNEE customers visited the company, the salesperson warmly received them and took photos. We look forward to more cooperation from new and old customers, and also warmly welcome your visit:
FAQ:
Q1: How can I get a quote?
A1: You can leave us a message, we will reply every message in time.
Q2: Can I get a sample before ordering?
A2: Of course you can. We can produce according to your samples or technical drawings. We are happy to provide you with samples, but do not provide shipping costs.
Q3: How do you build a long-term good relationship with us?
A3: We maintain good quality and competitive price to ensure the benefit of our customers. We respect every customer and regard them as friends, no matter where they come from, we will do business and make friends with them sincerely.
If you have any questions about us and our products, please feel free to leave us a message.
Hot Tags: A572 A514 Channel Steel, China A572 A514 Channel Steel manufacturers, suppliers, factory, A572 Channel Steel, metal u channel, ASTM Channel Steel, metal j channel, A36Channel Steel
