A572 A572 GR.50 Channel Steel
A572 Channel Steel is a new type of economic construction steel. It is mainly used for large buildings (such as factory buildings, high-rise buildings, etc.) with large cutting capacity and good cross-section stability, as well as bridges, ships, lifting and transportation machinery, equipment foundations, brackets, piles, and so on. Our products undergo strict quality testing and are equipped with professional certificates. If you have any questions about A572 channel steel, welcome to inspect them.
ASTM A572 GR 50 is a high strength low alloy steel. Grade 50 steel is difficult to form because it contains more alloy components than ordinary steel, but its strength per unit mass is higher. Because of its higher strength, ASTMA572 Grade 50 plate requires less material than ordinary carbon steel.
Products Description
| Product Name | A572 A572 GR.50 Channel Steel |
| Type | A572 A572 GR.50 |
| Size | 3# - 10# |
| Thickness | 3mm - 14.5mm |
| Length | 6m,9m,12m or other length based on demand |
| Surface Treatment | surface painted, galvanized |
| Packing | in bundle, packed with steel belts tightly |
A572 channel steel Chemical composition
| Item | Grade | Carbon, max, % | Manganese, max, % | Silicon, max, % | Phosphorus, max, % | Sulfur, max, % |
|---|---|---|---|---|---|---|
| A572 | 42 | 0.21 | 1.35 | 0.40 | 0.04 | 0.05 |
| 50 | 0.23 | 1.35 | 0.40 | 0.04 | 0.05 | |
| 55 | 0.25 | 1.35 | 0.40 | 0.04 | 0.05 |
a572 channel beam chemical composition
| Item | Grade | Yield point, min, ksi [MPa] | Tensile strength, min, ksi [MPa] |
|---|---|---|---|
| A572 | 42 | 42 290] | 60 [415] |
| 50 | 50 [345] | 65 [450] | |
| 55 | 55 [380] | 70 [485] |
a572 GR.50 c channel beam chemical composition
| Grade | C max |
Mn max |
P max |
S max |
SI max |
| A572Gr50 | 0.23 | 1.35 | 0.04 | 0.05 | 0.4 |
a572 GR.50 structural channel mechanical property
| Grade | Yield Strength Mpa |
Tensile Strength Mpa |
Elongation % in 200mm |
Elongation % in 50mm |
| A572Gr50 | 345 | 450 | 18 | 21 |
about GNEE group
GNEE (Tianjin) Multinational Trade Co., Ltd. was established in 2008 and is located in Anyang City, Henan Province, with strategic location and convenient transportation. We are a professional manufacturing and sales company. Our company's products include various specifications of steel plates, steel pipes, bars, profiles, etc. With good reputation and rich operating experience, our company has close cooperative relations with many Chinese and foreign enterprises and has won the trust and recognition of customers:
GNEE company’s August-September activities use games to increase team cohesion and demonstrate the unity of the team. At the same time, through this activity, we can cultivate the cooperation ability among employees:
GNEE company’s office environment and employee work style are displayed. New and old customers are welcome to visit. We will welcome your visit with great enthusiasm and provide you with professional steel services:
When GNEE customers visited the company, the salesperson warmly received them and took photos. We look forward to more cooperation from new and old customers, and also warmly welcome your visit:
Our products undergo strict quality testing and are equipped with professional certificates, if you have any questions about A572 A572 GR.50 Channel Steel, welcome to inspect them.
