Products Description
S235J0 is a structural steel grade specified in the EN 10025 standard, with a designation number of 1.0114. In this grade, "S" stands for structural steel, and "J0" indicates that the material has passed an impact test at 0°C.
Typical chemical composition of S235J0 includes: Carbon (C) ≤ 0.17%, Manganese (Mn) ≤ 1.40%, Phosphorus (P) ≤ 0.035%, Sulfur (S) ≤ 0.035%, and Silicon (Si) ≤ 0.55%.
Its mechanical properties include a minimum yield strength of 235 MPa, tensile strength ranging from 360–510 MPa, and elongation ≥ 26%. The steel also demonstrates good impact toughness at low temperatures, ensuring safety in structural applications.
S235J0 is commonly available in hot-rolled plates (thickness 4–120 mm), flat bars, square and round bars (diameter 10–200 mm), as well as profiles such as I-beams, H-beams, channels, and angles.
This steel is widely used in welded and bolted structures for bridges, buildings, industrial halls, and warehouses. It is also suitable for general mechanical parts that do not require heat treatment, including brackets, supports, and frames, offering reliable performance in medium-load structural applications.
Mechnical property for S235J0 steel plate
| Thickness (mm) | |||||||||
| S235J0 | ≤ 16 | > 16 ≤ 40 | > 40 ≤ 63 | > 63 ≤ 80 | > 80 ≤ 100 | > 100 ≤ 150 | > 150 ≤ 200 | > 200 ≤ 250 | > 250 |
| Yield strength (≥Mpa) | 235 | 225 | 215 | 215 | 215 | 195 | 185 | 175 | 175 |
| < 3 | ≥ 3 ≤ 100 | > 100 ≤ 150 | > 150 ≤ 250 | > 250 | |||||
| Tensile strength (Mpa) | 360-510 | 360-510 | 350-500 | 340-490 | 340-490 | ||||
Chemical composition for S235J0 steel plate (Ladle Analysis Max%
| Main chemical elements composition of S235J0 steel plate | |||||||
| Thickness(mm) | C | Si | Mn | P | S | N | Cu |
| T≤16 | 0.17 | ... | 1.40 | 0.030 | 0.030 | 0.012 | 0.55 |
| 16<T≤40 | 0.17 | ||||||
| 40<T | 0.17 | ||||||
S235J0 Steel Equivalent Grade Table
Europe(EN) |
Italy(UNI) |
France(NFA) |
German(DIN) |
Japan(JIS) |
|
S235J0 |
Fe360C |
E24-3 |
St37-3U |
SS400B |
Products application
S235J0 carbon steel coil is widely used in civil and industrial engineering projects due to its excellent structural properties and weldability. It is commonly applied in the construction of bridges, highways, and overpasses, for medium-load structural components such as beams, columns, and girders.
In addition to large-scale infrastructure, S235J0 steel coil is also suitable for building frameworks, industrial halls, warehouses, and other load-bearing structures. Its good cold-forming and machinability make it ideal for manufacturing welded and bolted assemblies.
Contact now to get S235J0 Quote
