Carbon Steel H Beam

Carbon steel H-beam is an important steel material widely used in construction, bridges, ships, machinery and other fields. Its excellent mechanical properties and welding properties make it play a pivotal role in modern industry.

Carbon steel H-beam is widely used in beam and column components of industrial and civil construction steel structure. Steel structure load-bearing support for industrial structures. Ship and machinery manufacturing frame structure. Steel piles and supporting structures of underground engineering, etc.

Product Standard & Grade

Standard	Grade
GB/T 700	Q2358,Q235C,Q235D
GB/T 1591	Q345B,Q345C,Q345D,Q345E,Q390B,Q390C,Q390D,Q390E,Q420B,Q420C,Q420D,Q420E,Q460C,Q460D,Q460E,Q500C,Q500D,Q500EA36, St37, S235J0, S235J2, St52, S355JR, Q195, Q215, Q235B, Q345B,
GB/T 4171	Q355NHB,Q355NHC,Q355NHD,Q355NHE,Q415NHB,Q415NHC,Q415NHD,Q415NHE,Q460NHB,Q460NHC,Q460NHD,Q460NHE
EN 10025-2	S235JR,S235J0,S275JR,S275J0,S275J2,S355JR,S355J0,S355J2,S355K2,S450J0
EN 10025-4	S355M,S355ML,S460M
EN 10025-5	S355J0WP,S355J2WP,S355J0W,S355J2W,S355K2W
ASTM A36/A36M	A36
ASTM A572/A572M	A572 Gr50,A572 Gr55,A572 Gr60,A572 Gr65
ASTM A992/A992M	A992
ASTM A131/A131M	GrA,GrB,GrD,GrE,AH32,DH32,EH32,FH32,AH36,DH36,EH36,FH36,AH40,DH40,EH40,FH40
ASTM A709/A709M	A709(Gr50F-1),A709(Gr50F-2),A709(Gr50F-3)
JIS G 3101	SS400
JIS G 3106	SM490A,SM490B
JIS G 3136	SN400A,SN400B,SN490B

Products Description

Size		1.Web Width (H): 100-900mm 2.Flange Width (B): 100-300mm 3. Web Thickness (t1): 5-30mm 4. Flange Thickness (t2): 5-30mm Or Customers' requirements
Length		6m, 9m, 12m or acording to customer requirements
Technology		Hot Rolled, Welded
Standard		ASTM, AISI, JIS, GB, DIN, EN
Surface		Galvanized, Painted or according to your requirements
Supply Capacity		20000 tons/Day
Business Type		Manufacturer
Certificate		ISO, SGS, BV
Application		Widely used in building structures and engineering construction, such as room beams, ship beams, industrial furnaces, etc.
Loading Port		Any port in China
Packaging		Standard export packing or as your request
Payment Method		Wire transfer, spot letter of credit, Western Union, payment documents, acceptance documents, PayPal.
