Hot Rolled SUS H Profile
An economical cross-section profile with a cross-sectional shape similar to the capital Latin letter H, also called universal steel beam, wide-edge (side) I-beam, or parallel-flange I-beam.Usually H-Beam are used as the main structure of building, like for example, things such as poles, beam for residential buildings, or even component such as trusses, and cantilevers. Other scope of uses involves process such as cutting, extending, welding and securing with bolts to support specific structures.
Hot Rolled SUS H Profile the detail :
|
Product Name |
Hot Rolled SUS H Profile |
|
Length |
1m - 12m , or according to your requests. |
|
Standard |
GB ASTM, JIS, SUS, DIN, EN etc |
|
Size |
1.Web Width (H): 100-900mm |
|
MOQ |
1 Ton |
|
Payment |
30%TT for deposit, 70% balance before shipment or LC at sight |
|
Packing |
Export standard packing or according to customers’ requirement |
Hot-rolled H-shaped steel reasonably distributes the aspect ratio of the cross-section size according to different uses, and has excellent mechanical properties and superior usability.
★High structural strength. Compared with I-beam, the section modulus is larger, and 10-15% of metal can be saved under the same load-bearing conditions.
★The design style is flexible and rich. When the beam height is the same, the bays of the steel structure can be 50% larger than those of the concrete structure, making the building layout more flexible.
★The structure is light in weight. It is lighter than the self-weight of a concrete structure. The reduction of the structure's self-weight reduces the internal force of the structural design, which can make the building structure foundation processing requirements lower, the construction is simple, and the cost is reduced.
| H BEAM size | ||||||
| size | h (MM) |
b (MM) |
t1 (MM) |
t2 (MM) |
Mass: Kg/m | LENGTH |
| 100x100 | 100 | 100 | 6.0 | 8 | 16.9 | 12M |
| 125x125 | 125 | 125 | 6.5 | 9 | 23.6 | 12M |
| 150x75 | 150 | 75 | 5.0 | 7 | 14.0 | 12M |
| 148x100 | 148 | 100 | 6.0 | 9 | 20.7 | 12M |
| 150x150 | 150 | 150 | 7.0 | 10 | 31.1 | 12M |
| 175x90 | 175 | 90 | 5.0 | 8 | 18.0 | 12M |
| 175x175 | 175 | 175 | 5.0 | 11 | 40.4 | 12M |
| 198x99 | 198 | 99 | 4.5 | 7 | 17.8 | 12M |
| 200x100 | 200 | 100 | 5.5 | 8 | 20.9 | 12M |
| 194x150 | 194 | 150 | 6.0 | 9 | 29.9 | 12M |
| 200x200 | 200 | 200 | 8.0 | 12 | 49.9 | 12M |
| 200x204 | 200 | 204 | 12.0 | 12 | 56.2 | 12M |
| 248x124 | 248 | 124 | 5.0 | 8 | 25.1 | 12M |
| 250x125 | 250 | 125 | 6.0 | 9 | 29.0 | 12M |
| 244x175 | 244 | 175 | 7.0 | 11 | 43.6 | 12M |
| 250x250 | 250 | 250 | 9.0 | 14 | 71.8 | 12M |
| 250x255 | 250 | 255 | 14.0 | 14 | 81.6 | 12M |
| 298x149 | 298 | 149 | 5.5 | 8 | 32.0 | 12M |
| 300x150 | 300 | 150 | 6.5 | 9 | 36.7 | 12M |
| 294x200 | 294 | 200 | 8.0 | 12 | 55.8 | 12M |
| 294x302 | 294 | 302 | 12.0 | 12 | 83.4 | 12M |
| 300x300 | 300 | 300 | 10.0 | 15 | 93.0 | 12M |
| 300x305 | 300 | 305 | 15.0 | 15 | 105.0 | 12M |
| 346x174 | 346 | 174 | 6.0 | 9 | 41.2 | 12M |
| 350x175 | 350 | 175 | 7.0 | 11 | 49.4 | 12M |
| 340x250 | 340 | 250 | 9.0 | 14 | 78.1 | 12M |
| 344x348 | 344 | 348 | 10.0 | 16 | 113.0 | 12M |
| 350x350 | 350 | 350 | 12.0 | 19 | 135.0 | 12M |
| 396x199 | 396 | 199 | 7.0 | 11 | 56.1 | 12M |
| 400x200 | 400 | 200 | 8.0 | 13 | 65.4 | 12M |
| 400x300 | 400 | 300 | 10.0 | 16 | 105 | 12M |
| 388x402 | 388 | 402 | 15.0 | 15 | 140 | 12M |
| 394x398 | 394 | 398 | 11.0 | 18 | 147 | 12M |
| 400x400 | 400 | 400 | 13.0 | 21 | 172 | 12M |
| 400x408 | 400 | 408 | 21.0 | 21 | 197 | 12M |
| 414x405 | 414 | 405 | 18 | 28 | 232 | 12M |
| 428x407 | 428 | 407 | 20 | 35 | 283 | 12M |
| 458x417 | 458 | 417 | 30 | 50 | 415 | 12M |
| 498x432 | 498 | 432 | 45 | 70 | 605 | 12M |
| 446x199 | 446 | 199 | 8 | 12 | 65.1 | 12M |
| 450x200 | 450 | 200 | 9 | 14 | 74.9 | 12M |
| 440x300 | 440 | 300 | 11 | 18 | 121 | 12M |
The above is some standard size information!
Please contact us for more standard size information!
