CARBON STEEL H BEAM S275JO
CARBON STEEL H BEAM S275JO is an intermediate tensile strength carbon steel that is easy to form, machine and weld. Its strength and low cost make it an ideal material for structural steel beams.
CARBON STEEL H BEAM S275JO are used for support beams and columns in bridges, buildings and other structural applications that require riveting, bolting or welding to join the beams together or to other components.
S275JO carbon h profile steel chemical composition
| C | Mn | P | S | N | Cu | CEV |
| max 0.18 | max 1.5 | max 0.035 | max 0.035 | max 0.012 | max 0.55 | max 0.42 |
S275JO carbon steel h beam mechanical properties
| Nominal thickness (mm): | to 3 | 3 - 100 | 100 - 150 | 150 - 250 |
| Rm - Tensile strength (MPa) Flat and long products | 430-580 | 410-560 | 400-540 | 380-540 |
| Nominal thickness (mm): | to 16 | 16 - 40 | 40 - 63 | 63 - 80 | 80 - 100 | 100 - 150 | 150 - 200 | 200 - 250 |
| ReH - Minimum yield strength (MPa) Flat and long products | 275 | 265 | 255 | 245 | 235 | 225 | 215 | 205 |
| KV - Impact energy (J) longitud., | -20° 27 |
0° 27 |
+20° 27 |
| Nominal thickness (mm): | to 1 | 1 - 1.5 | 1.5 - 2 | 2 - 2.5 | 2.5 - 3 |
| A - Min. elongation Lo = 80 mm (%) parallel, | 15 | 16 | 17 | 18 | 19 |
| Nominal thickness (mm): | 3 - 40 | 40 - 63 | 63 - 100 | 100 - 150 | 150 - 250 |
| A - Min. elongation Lo = 5,65 √ So (%) parallel, | 23 | 22 | 21 | 19 | 18 |
Products Description
| EU EN |
USA - |
Germany DIN,WNr |
France AFNOR |
England BS |
European old EN |
Italy UNI |
Belgium NBN |
Spain UNE |
China GB |
Austria ONORM |
Norway NS |
Russia GOST |
Inter ISO |
Portugal NP |
India IS |
||||||||||||||||||
| S275J0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
S275JO carbon steel beam image display
S275JO carbon H beam steel is a readily weldable low carbon manganese steel with good impact resistance. This material is commonly supplied in the untreated or normalized condition.
Machinability of this material is similar to that of mild steel.
Gnee Steel stocks a wide range of steel beam sizes for thousands of applications. Shop online for standard or cut to size lengths at wholesale steel beam prices. We also offer a selection of Galvanized Steel Beams. Just give us a call if you need something special.
Note: Steel Beams may have areas with minor surface rust scale or discoloration due to the nature of the product. This is normal and in no way effects the integrity of the product.
company profile
A group photo of the GNEE company team. We were founded in 2008. We have rich experience in steel export and have established cooperative relationships with more than 120 countries and regions around the world. If you have any steel needs, please contact us and we will provide you with high-quality services. , to meet your purchasing needs, and also welcome new and old customers to visit:
GNEE Group office environment display, welcome new and old customers to visit. At the same time, if you have any questions about steel h beam, you can contact us and we will reply to you in the shortest time:
GNEE company’s August-September activities use games to increase team cohesion and demonstrate the unity of the team. At the same time, through this activity, we can cultivate the cooperation ability among employees:
When GNEE customers visited the company, the salesperson warmly received them and took photos. We look forward to more cooperation from new and old customers, and also warmly welcome your visit:
qualifications and honors
GNEE company has passed SGS CE ISO and other certifications, has complete testing equipment, strong technical force, and accepts factory testing. We firmly believe that "quality is the core of a company's sustainable strength". We will establish stable, long-term, win-win cooperative relationships with our customers and stick to them:
cooperation factories
GNEE Company has signed first-level agency agreements with some large steel plants such as Baosteel, Maanshan Iron and Steel, and Anshan Iron and Steel, which has a strong price war advantage. We are committed to strict quality control and thoughtful customer service, and our experienced staff are always ready to listen to your requirements to ensure full customer satisfaction:
packing & shipping
|
Packing |
1.Generally package:Anti-water paper+strapped with min three strapping strips. |
|
2.Standard exporting package: Anti-water paper and plastic+covered by iron sheet+ strapped withmin three strapping strips. |
|
|
3.Excellent package:Anti-water paper and plastic film+ covered by iron sheet+ strapped with minthree strapping strips+fixed on the iron or wooden pallets by strapping strips. |
|
|
Shipping |
1.Shipping by containers |
|
2.Shipping by bulk ship. |
