S235 S255 Channel Steel
S255 is a low-alloy high-strength structural steel that meets the requirements of EN 10025-2. It is an alloy-free hot-rolled structural steel in European standards. The designation S255 indicates that its minimum yield strength is 25 MPa.
Steel grade S235 contains 2-3% manganese, 0.1% carbon and 1.5% copper. These components give S235 grade steel excellent strong plasticity. At the same time, this steel also contains trace amounts of P and S, which is very helpful in improving its processing performance and weldability. S235 steel is mainly composed of Mn, which has a certain improvement effect on its mechanical properties.
S235 S255 Channel Steel Basic Info
| Name | S235 S255 Channel Steel |
| Type | S235 |
| Size | 5# - 10# |
| Thickness | 3mm - 14.5mm |
| Length | 6m,9m,12m or other length based on demand |
| Grade |
Q235,Q355,SS400,S235,S355,ST37,ST52,E250,E350, A36,A572GR50,A992,G350,SM460,SM490,A992 |
| Surface | Surface painted, galvanized |
| Packing | in bundle, packed with steel belts tightly |
s255 structural channel chemical composition
| C | Si | Mn | Ni | S | P | Cr | N | Cu | Al | Ti |
| ≤0.17 | 0.15 - 0.30 | ≤ 1,00 | ≤0.30 | ≤0.025 | ≤0.035 | ≤0.30 | ≤0.012 | ≤0.30 | 0.02-0.05 | ≤ 0,030 |
s235 channel steel chemical composition
| C | Si | Mn | Ni | S | P | Cr | N | Cu |
| ≤0,22 | ≤0,05 | ≤0,60 | ≤0,30 | ≤0,040 | ≤0,040 | ≤0,30 | ≤0,012 | ≤0,30 |
s255 c channel steel mechanical property
| Thickness, mm | Yield strength, N/mm2 (min) | Tensile strength, N/mm2 (min) | Elongation δ5, % |
| 2 - 3.9 | 255 | 380 | 20 |
| 4 - 10 | 245 | 380 | 25 |
| 10 - 20 | 245 | 370 | 25 |
| 20 - 40 | 235 | 370 | 25 |
s235 c channel metal mechanical property
| Thickness, mm | Yield strength, N/mm2 (min) | Tensile strength, N/mm2 (min) | Elongation δ5, % |
| 2,0-3,9 | 235 | 360 | - |
| 4,0 | 235 | 360 | - |
Products Description
The S235 channel steel is not used as much in construction as symmetrical beams, in part because its bending axis is not centered on the width of the flanges. If a load is applied equally across its top, the beam will tend to twist away from the web. This may not be a weak point or problem for a particular design, but is a factor to be considered.
Channels or C-beams are often used where the flat, back side of the web can be mounted to another flat surface for maximum contact area. They are also sometimes welded together back-to-back to form a non-standard I-beam.
Application
Bridge Road
