Shipbuilding Industry With Angle Steel
Angle steel for ships is a kind of steel used in the shipbuilding industry, and it is included in the category of profiles. Before building a ship, there must be corresponding certificates and corresponding steel seals from the nine major classification societies such as CCS, BV, LR, GL, and DNV.
Common angle steel used in the shipbuilding industry includes: AH36, DH36, EH36 and other materials, which we can customize according to your needs.
Products Details
Shipbuilding Industry With Angle Steel the information :
|
Name |
Shipbuilding Industry With Angle Steel | |
|
Standard |
AISI, ASTM, BS, DIN, GB, JIS, etc |
|
|
Material |
ss400 Q235B s235JR ... |
|
|
Thickness |
3-24mm |
|
|
Equal Angle |
Type: |
2#-20# |
|
Size: |
20-200mm |
|
|
Thickness: |
3.0-24mm |
|
|
Weight: |
0.597-71.168kg/m |
|
|
Unequal Angle |
Type: |
2.5*1.6-20*12.5# |
|
Size: |
25*16-200*125mm |
|
|
Long Side: |
20-200mm |
|
|
Short Side: |
16-125mm |
|
|
Thickness: |
3.0-24mm |
|
|
Weight: |
1.687-43.588kg/m |
|
|
Length |
1-12m or as customer request |
|
|
Surface |
Oil, Black, Galvanized, Painted |
|
|
Technique |
Hot rolled/Cold rolled/Galvnized |
|
|
Application |
Mechanical&manufacturing,Steel structure,Shipbuilding,Bridging,Automobile classis,Construction,Decoration,etc. |
|
|
Package |
By bundles with steel strips or according to the requirements of customers |
|
AH36 angle iron chemical composition and mechanical properties
| % | |
|---|---|
| C | 0.18 |
| Si | 0.10/0.50 |
| Mn | 0.90/1.60 |
| P | 0.035 |
| S | 0.035 |
| Cr | 0.20 |
| Mo | 0.08 |
| Ni | 0.40 |
| Cu | 0.35 |
| Cb | 0.02/0.05 |
| V | 0.05/0.10 |
| GRADE | RE | RM | ELONGATION | |
|---|---|---|---|---|
| A50mm | A200mm | |||
| MPa | MPa | % | % | |
| AH36 | 355 | 490/620 | 22 | 19 |
DH36 steel angle chemical composition and mechanical properties
| % | |
|---|---|
| C | 0.18 |
| Si | 0.10/0.50 |
| Mn | 0.90/1.60 |
| P | 0.035 |
| S | 0.035 |
| Cr | 0.20 |
| Mo | 0.08 |
| Ni | 0.40 |
| Cu | 0.35 |
| Cb | 0.02/0.05 |
| V | 0.05/0.10 |
| GRADE | RE | RM | ELONGATION | |
|---|---|---|---|---|
| A50mm | A200mm | |||
| MPa | MPa | % | % | |
| DH36 | 355 | 490/620 | 22 | 19 |
EH36 angle bar chemical composition and mechanical properties
| % | |
|---|---|
| C | 0.18 |
| Si | 0.10/0.50 |
| Mn | 0.90/1.60 |
| P | 0.035 |
| S | 0.035 |
| Cr | 0.20 |
| Mo | 0.08 |
| Ni | 0.40 |
| Cu | 0.35 |
| Cb | 0.02/0.05 |
| V | 0.05/0.10 |
| GRADE | RE | RM | ELONGATION | |
|---|---|---|---|---|
| A50mm | A200mm | |||
| MPa | MPa | % | % | |
| EH36 | 355 | 490/620 | 22 | 19 |
about us
Group photo of GNEE(Tianjin) Multinational Trade Co. team. We were established in 2008 and are located in Anyang City, Henan Province, with a superior geographical location and convenient transportation. We are a professional manufacturing and sales company. Our company's products include various specifications of steel plates, steel pipes, bars, profiles, etc. With good reputation and rich operating experience, our company has close cooperative relations with many Chinese and foreign enterprises and has won the trust and recognition of customers.
GNEE company's office environment and employee work style are displayed. New and old customers are welcome to visit. We will welcome your visit with great enthusiasm and provide you with professional steel services:
The Profile steel team and other teams actively participated in GNEE's August and September activities, for the sake of a better team atmosphere and to better serve customers:
GNEE company organized a trip to Penglai Island. Profile steel team members and other team members actively participated to create a good team atmosphere:
When GNEE customers visited the company, the salesperson warmly received them and took photos. We look forward to more cooperation from new and old customers, and also warmly welcome your visit:
FAQ
Q: WHY SHOULD I CHOOSE YOU?
A: Choose happens because of quality,then price, we can give you both. Additionally, we can also offer professional products inquiry, products knowledge train( for agents), smooth goods delivery, excellent customer solution proposals.
Our service formula:good quality + good price + good service = Customer's trust
Q: HOW LONG IS YOUR DELIVERY TIME?
A: Generally it is 10 days if the goods are in stock. or it is 30 days if the goods are not in stock, it is according to quantity.
Q: DO YOU PROVIDE SAMPLES ? IS IT FREE OR EXTRA ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: WHAT IS YOUR TERMS OF PAYMENT ?
A: We accept LC and TT both.
Hot Tags: shipbuilding industry with angle steel, China shipbuilding industry with angle steel manufacturers, suppliers, factory
