corten sheets Product Introduction
ASME SA588 Grade A Cowden steels are alloy steels manufactured to provide the best corrosion resistant products. These steels have high mechanical strength and are suitable for various applications. The corrosion resistance of these steels is a result of this A588 Grade A Corten Steel Plate forming a protective layer on the surface of the plate when in contact with corrosive gases.
A588 Grade A steel plates offer physical properties such as high surface finish, dimensional accuracy, and structural robustness. These steels are low maintenance and can be used to manufacture a wide range of products with excellent resistance to corrosion, heat and pressure. They are widely used in air preheaters, coal economizers, railroad cars, container production, and bridge construction.
ASME SA588 A Specifications:
Thickness: 3 mm - 150 mm
Width: 30 mm - 4000 mm
Length: 1000 mm - 12000 mm
Standard: ASTM EN10025 JIS GB
weathering corten steel
weathering steel Product Details
SA588 Gr A chemical composition:
|
Grades |
C max |
Mn |
P max |
S max |
Si |
Ni max |
Cr |
Cu |
V |
|
SA588GR.A |
0.19 |
0.80-1.25 |
0.04 |
0.05 |
0.30-0.65 |
0.40 |
0.40-0.65 |
0.25-0.55 |
0.02-0.10 |
SA588 Gr A tensile property:
|
ASME SA588 Grade A |
Plates and bars |
Structural shapes |
||
|
＜100mm |
≥100-125mm |
＞125-200 |
||
|
Tensile strength min MPa |
485 |
460 |
435 |
485 |
|
Yield strength min MPa |
345 |
315 |
290 |
345 |
|
Elongation min |
21 |
21 |
21 |
21 |
corten steel material
GNEE Group receives visiting customers
We are committed to providing the highest quality steel products. Our stringent quality control measures ensure that every product that leaves the factory meets the most stringent international standards.
corten steel supplier
If you have more needs and questions about steel, please contact us!
